Waterbath WTB35
Waterbath WTB35

Memmert Waterbath

Standard delivery Waterbath

On this page, you can find all the essential technical data on the Memmert water bath. Our customer relations team will be pleased to help if you want further information. If you should require a customised special solution, please contact our technical specialists at sales@memmert.com.

Request Inquiry
Category:

Description

Water bath WTB with working temperature range: +5°C above the ambient temperature up to +100°C.

Intuitive and user friendly – Memmert is known for excellent operating concepts – the new WTB water baths are just more proof of this. The touchscreen impresses with its intuitive and convenient menu navigation. A particular highlight: Thanks to the personalisable remote viewing through the CustomView, you always have an eye on the important information.

Practical and robust – Perfect for everyday use in the laboratory: The high-quality stainless steel container with rounded corners is easy to clean and can be completely drained using the standard drain valve without residue left behind. The compact ergonomic design means the Memmert WTB fits on any laboratory table.

Can be expanded in a flexible and modular way – The modular concept of this modern water bath guarantees maximum flexibility. If the application calls for it, a circulation pump, cooling unit, shaking device and test tube holder or insertable rack can easily be retrofitted.

Sketch Waterbath WTB35

Memmert Laboratory Equipment

Temperature

Temperature sensor digital temperature sensor, mounted on the outside of the bath
Temperature Setting Celsius / Fahrenheit
Working temperature range at least 5 above ambient to +100 (with cover, depending on ambient pressure)
Setting temperature range +10 to +100 °C
Setting accuracy temperature 0.1 °C

Control technology

Calibration 2-point calibration
Controller intuitive 3.5" colour graphic display with touch screen
Controller digital display of set and actual temperature and of (remaining) programme time

Safety

Temperature control two-stage safety system to prevent overtemperature
Temperature control individually adjustable overtemperature alarm, visual and acoustic
Temperature control Independent temperature limiter to switch off the heating in case of failure
Autodiagnostic system microprocessor PID-temperature controller with integrated autodiagnostic system with fault indicator

Heating concept

Heating corrosion-proof large-area heating on the outside of the interior

Standard equipment

Cover Stainless steel gable cover
Drain system innovative drain system - easy to empty
Timer digital timer from 1 min. up to 99 hours 59 min., visual and acoustic

Stainless steel interior

Interior Deep-drawn stainless steel tray (stainless steel W.St. 1-4301), without corners and edges for easy cleaning incl. central drain (no disturbing installations)
Dimensions W x H x D in mm w(A) x h(C) x d(B): 602 x 150 x 482 mm
Volume 37 l
Liquid level min. 20 mm
Liquid level max. 114 mm

Textured stainless steel casing

Dimensions w(D) x h(E2) x d(F): 674 x 348 x 554 mm

Electrical data

Voltage Electrical load 230 V, 50/60 Hz approx. 2800 W
Voltage Electrical load 115 V, 50/60 Hz approx. 2000 W

Ambient conditions

Installation The vent openings in the left and back side must remain unobstructed. Minimum wall spacing on all sides is 80 mm. The minimum spacing from the top of the bath to the next ceiling is 750 mm.
Ambient temperature +5 °C to +40 °C
Humidity rh max. 80 %, non-condensing
Overvoltage category II
Pollution degree 2

Packing/shipping data

Transport information The appliances must be transported upright
Customs tariff number 8419 8998
Country of origin Federal Republic of Germany
WEEE-Reg.-No. DE 66812464
Dimensions approx incl. carton w x h x d: 910 x 610 x 400 mm
Net weight approx. 14 kg
Gross weight carton approx. 20 kg
